Circuit Module Physical Construction
Table 4. bq76930EVM Circuit Module Bill of Materials (continued)
Designator Qty Value Description Package Reference Part Number MFR Alt. Part Number Alt. MFR
R76, R124, R125, R126, R127, 0 200 RES, 200 ohm, 1%, 0.125W, 0805 0805 CRCW0805200RFKEA Vishay-Dale
R128
R84 0 300k RES, 300k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-304-B-T5 Susumu Co Ltd
R85 0 0 RES, 0 ohm, 5%, 0.25W, 1206 1206 CRCW12060000Z0EA Vishay-Dale
R88, R93 0 100k RES, 100k ohm, 0.1%, 0.1W, 0603 0603 RG1608P-104-B-T5 Susumu Co Ltd
R91, R92, R100 0 1.00Meg RES, 1.00Meg ohm, 1%, 0.125W, 0805 0805 CRCW08051M00FKEA Vishay-Dale
RT3 0 10.0k ohm Thermistor NTC, 10.0k ohm, 1%, Disc, 5x8.4 mm Disc, 5x8.4 mm 103AT-2 SEMITEC Corporation
TP1 0 Black Test Point, TH, Multipurpose, Black Keystone5011 5011 Keystone
TP2, TP14 0 Red Test Point, TH, Multipurpose, Red Keystone5010 5010 Keystone
TP7, TP8, TP10, TP11, TP13, 0 White Test Point, TH, Multipurpose, White Keystone5012 5012 Keystone
TP15, TP16, TP17, TP18, TP19,
TP20, TP21, TP22, TP23, TP24,
TP25, TP26, TP27, TP28, TP29,
TP30, TP31, TP32, TP33, TP34,
TP35, TP36, TP40, TP41, TP42,
TP43, TP44, TP45, TP52, TP56,
TP57, TP58, TP60
TP50 0 Yellow Test Point, Multipurpose, Yellow, TH Yellow Multipurpose 5014 Keystone
Testpoint
Notes:
Unless otherwise noted in the Alternate Part Number and/or Alternate Manufacturer columns, all parts may be substituted with equivalents.
