www.ti.com

Jumper J4

Open to disconnect LED

Orient Pin 1 of

MSP430 device

Jumper J5

Open to measure current

Connector J3

External power connector

Remove R8 and jumper R9

LED connected to P1.0

Schematics and PCBs

Figure B-6. MSP-TS430DW28 Target Socket Module, PCB

SLAU138F – June 2004 – Revised March 2007 Hardware 43

Submit Documentation Feedback
