(1) Registers in this table are mapped to Peripheral Frame 2 space. This space only allows 16-bit accesses. 32-bit accesses produce
undefined results.
(2) These registers are new registers for the FIFO mode.
The SCI port operation is configured and controlled by the registers listed in Table 6-39 and Table 6-40.
Table 6-39. SCI-A Registers
(1)
NAME ADDRESS SIZE (×16)
EALLOW
PROTECTED
DESCRIPTION
SCICCRA 0x7050 1 No SCI-A Communications Control Register
SCICTL1A 0x7051 1 No SCI-A Control Register 1
SCIHBAUDA 0x7052 1 No SCI-A Baud Register, High Bits
SCILBAUDA 0x7053 1 No SCI-A Baud Register, Low Bits
SCICTL2A 0x7054 1 No SCI-A Control Register 2
SCIRXSTA 0x7055 1 No SCI-A Receive Status Register
SCIRXEMUA 0x7056 1 No SCI-A Receive Emulation Data Buffer Register
SCIRXBUFA 0x7057 1 No SCI-A Receive Data Buffer Register
SCITXBUFA 0x7059 1 No SCI-A Transmit Data Buffer Register
SCIFFTXA
(2)
0x705A 1 No SCI-A FIFO Transmit Register
SCIFFRXA
(2)
0x705B 1 No SCI-A FIFO Receive Register
SCIFFCTA
(2)
0x705C 1 No SCI-A FIFO Control Register
SCIPRIA 0x705F 1 No SCI-A Priority Control Register
(1) Registers in this table are mapped to Peripheral Frame 2 space. This space only allows 16-bit accesses. 32-bit accesses produce
undefined results.
(2) These registers are new registers for the FIFO mode.
Table 6-40. SCI-B Registers
(1)
NAME ADDRESS SIZE (×16) DESCRIPTION
SCICCRB 0x7750 1 SCI-B Communications Control Register
SCICTL1B 0x7751 1 SCI-B Control Register 1
SCIHBAUDB 0x7752 1 SCI-B Baud Register, High Bits
SCILBAUDB 0x7753 1 SCI-B Baud Register, Low Bits
SCICTL2B 0x7754 1 SCI-B Control Register 2
SCIRXSTB 0x7755 1 SCI-B Receive Status Register
SCIRXEMUB 0x7756 1 SCI-B Receive Emulation Data Buffer Register
SCIRXBUFB 0x7757 1 SCI-B Receive Data Buffer Register
SCITXBUFB 0x7759 1 SCI-B Transmit Data Buffer Register
SCIFFTXB
(2)
0x775A 1 SCI-B FIFO Transmit Register
SCIFFRXB
(2)
0x775B 1 SCI-B FIFO Receive Register
SCIFFCTB
(2)
0x775C 1 SCI-B FIFO Control Register
SCIPRIB 0x775F 1 SCI-B Priority Control Register
