2
TMS320F28069
,
TMS320F28068
,
TMS320F28067
,
TMS320F28066
TMS320F28065, TMS320F28064, TMS320F28063, TMS320F28062
SPRS698F –NOVEMBER 2010–REVISED MARCH 2016
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS320F28069 TMS320F28068 TMS320F28067 TMS320F28066 TMS320F28065
TMS320F28064 TMS320F28063 TMS320F28062
Device Overview Copyright © 2010–2016, Texas Instruments Incorporated
1.2 Applications
• Switch Mode Power Supplies (SMPSs)
• Solar Micro Inverters and Converters
• Power Factor Correction (PFC)
• Smart Grid and Power Line Communications
• AC/DC Inverters
1.3 Description
The F2806x Piccolo™ family of microcontrollers (MCUs) provides the power of the C28x core and CLA
coupled with highly integrated control peripherals in low pin-count devices. This family is code-compatible
with previous C28x-based code, and also provides a high level of analog integration.
An internal voltage regulator allows for single-rail operation. Enhancements have been made to the High-
Resolution Pulse Width Modulator (HRPWM) module to allow for dual-edge control (frequency
modulation). Analog comparators with internal 10-bit references have been added and can be routed
directly to control the ePWM outputs. The ADC converts from 0 to 3.3-V fixed full-scale range and
supports ratio-metric V
REFHI
/V
REFLO
references. The ADC interface has been optimized for low overhead
and latency.
(1) For more information on these devices, see Section 9, Mechanical Packaging and Orderable
Information.
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE
TMS320F28069PZP HTQFP (100) 14.0 mm × 14.0 mm
TMS320F28069PFP HTQFP (80) 12.0 mm × 12.0 mm
TMS320F28069PZ LQFP (100) 14.0 mm × 14.0 mm
TMS320F28069PN LQFP (80) 12.0 mm × 12.0 mm
