External Monito r
Supported Monitors
The computer supports the following multifrequency
external and
VGA monitors.
❑ 31kHz/70 Hz (400/200 line mode)
❑ 60 Hz (480 line mode)
❑ IBM PS/2 monitors
❑ Multiscanning monitors covering 15.75 to 31.5 kHz,
50 to 70 Hz
Installing an External Monitor
c
Caution: Always turn off the computer before connect-
ing an external monitor.
1. Turn off power to both the external monitor and the
computer.
2. Connect the 15-pin external
VGA monitor cable to the
15-pin connector on the back panel of the computer.
3. Turn on power to the computer first; then turn on the
external monitor.
4. Switch the display between the
LCD and the external
monitor by double clicking the Windows Notebook
Group menu CRT or Panel icon. Alternatively, you
may type:
LCD, PANEL, SIMUL VGA UTILS
at the
MS-DOS C:\ prompt and press ENTER.
External Monitor
11-14 TravelMate Options
