6.0 Connecting to the panel
The SmartCom requires two Com ports on the control panel. The 4 wire connector
identified as SmartCom in the panel Com Port device list, the two wire connector
identified as ComIP in the panel Com Port device list.
A Premier Elite ComPort+ is provided which may be used to utilise the digi modem
connection to provide Com Port 3 on Premier Elite 48/64/88 & 168. Premier Elite
640 has 3 com ports on the PCB.
Insert the black connector into the
SmartCom.
Note: the yellow wire should be on the
upper right hand side.
