INS760EN-7 67/91
12.0 Specifications
Specifications
Alarm System
Grade 2 Environmental Class II
EN50131-1, EN50131-10:2014,
EN50136-1:2012, EN50136-2:2013,
PD6669:2017, PD6662:2017
Alarm Transmission System
Categories
Premier Elite 640 SP3
Premier Elite 168 SP3
Premier Elite 88 SP3
Premier Elite 64-W SP2
Premier Elite 48 SP2
Premier Elite 24 SP2
Panel Log size
Premier Elite 640 1000
Premier Elite 168 1000
Premier Elite 88 1000
Premier Elite 64-W 500
Premier Elite 48 500
Premier Elite 24 500
Product Type
Ethernet and WiFi - CELA0000
Ethernet only - CELA1000
Ethernet 10/100 Base-T, 100 Base-TX
WiFi Module 2.4GHz IEE802.11 (b/g/n)
WiFi Max RF Power 15 dbm - Internal Antenna
Operating Voltage 8 - 15 Vdc
Typical Current
Average Peak
90mA 140mA
Supported Protocols Contact ID & SIA II/III
Interconnection Type
Interconnection between device and CIE is
proprietary and can only be used with a
Texecom CIE
Relative Humidity 0 - 95% non-condensing
Certified by
BRE
