Wintex please ensure the com port used is programmed as "Nothing Fitted".
14.0 Appendix B
Power Up & Initial Config - Flash Upgraded Panel
After flash upgrading the control panel and installing any additional wired devices,
the system can be powered up.
It is critical that the defaults are loaded during the initial power up to ensure the
control panel is loaded with the correct factory configuration.
Locate the "Load Defaults" button and the "Heartbeat" LED on the PCB
Press and hold the "Load defaults" button and apply power to the panel.
Release the "Load Defaults" button when the "Heartbeat" LED starts flashing
rapidly.
The Keypad display will look like this:
To Next Page
Loading...
