6.11.X-Ray Management
6.12.Performance
6.12.1. PIXIUM PORTABLE EZ-C HD Series
The detector does not include built-in X-Ray shielding, except some thin and narrow lead plates
for electronic components protection. Protection of operator and patient against transmitted X-Ray
shall be considered by the end user (either with protective clothing or other suitable means).
Do not shoot X-rays when a dysfunction of the detector is noticed, either by the LED indicators or
at system level.
In case of loss of communication with the detector, the system sends an alarm to the integrator
system. It is integrator responsibility to manage the x-ray exposure.
Thales KEYWORD ITEM Unit Typ min Max
cumulate.d_dose
Allowable Integrated
dose over lifetime
Gy - 100 -
func_lifetime Detector life time year 10 - -
ITEM Unit Typ min Max
X-ray kVp range kVp - 40 150
MTF @ 0.5 lp/mm % 82 79 -
MTF @ 1 lp/mm % 62 56 -
MTF @ 1.5 lp/mm % 46 40 -
MTF @ 2 lp/mm % 33 27 -
MTF @ 2.5 lp/mm % 24 18 -
MTF @ 3 lp/mm % 17 13 -
MTF @ 3.5 lp/mm % 12 8 -
MTF @ 4 lp/mm % 8 6 -
MTF @ 4.5 lp/mm % 6 4 -
DQE @ 0 lp/mm (2 µGy) % 69 60 -
DQE @ 0.5 lp/mm (2 µGy) % 57 51 -
DQE @ 1 lp/mm (2 µGy) % 50 44 -
