8. LED INDICATORS
8.1. LED Location
8.1.1. PIXIUM EZ-C HD Series
8.2. LED Indicator PIXIUNM EZ-C HD Series
Symbol:
The following behavior is applicable to OPERATING, LISTEN, DOWNLOAD and ERROR states:
Symbol Meaning
BAT
• Is lit when the Pixium EZ HD is powered on or
connected to a DC power supply.
• Is flashing when battery is not full.
• Keeps green when battery is full.
Battery NFC
Link
Status
Power
