Checking System Status
After making connections on the N5200 and powering up, check whether the
system status is normal or has trouble by observing indicators on the front panel
and hard disk trays.
System Status Normal
The system status is normal if:
1. The WAN and LAN LEDs glow
green (assuming both are
connected).
2. The Power LED on the Front
Panel glows blue.
).
3. The HDD Power LED on each
HDD tray glows blue (assuming
all disks are installed
4. The default IP address of the
WAN port is 192.168.1.100.
System Trouble
The system has trouble if:
1. System Busy LED glows red.
If the system has trouble, please
refer to Chapter 8:
Troubleshooting.
WARNING
There are no user serviceable parts inside the N5200.
your distributor for service.
Please contact
15
