8. Finished! Access the N5200 Web Administrator Interface by pressing the
Start Browser button. You can also configure another N5200 at this point
by clicking the Setup Other Device button. Press Exit to exit the wizard.
The Thecus Setup Wizard is designed for installation on systems
running Windows XP/2000 or Mac OSX or later. Users with other
operating systems will need to install the Thecus Setup Wizard on a
host machine with one of these operating systems before using the
unit.
NOTE
LCD Operation
The N5200 is equipped with an LCD on the front for easy status display and setup.
There are four buttons on the front panel to control the LCD functions.
LCD Controls
Use the Up (▲), Down (▼), Enter (↵) and Escape (ESC) keys to select various
configuration settings and menu options for N5200 configuration.
The following table illustrates the keys on the front control panel:
LCD Controls
Icon Function Description
▲
Up Button Select the previous configuration settings option.
▼
Down Button Select the next configuration settings option.
↵
Enter Enter the selected menu option, sub-menu, or parameter setting.
ESC Escape Escape and return to the previous menu.
There are two modes of operation for the LCD: Display Mode and Management
Mode.
Display Mode
During normal operation, the LCD will be in Display Mode.
Display Mode
Item Description
Host Name Current host name of the system.
WAN Current WAN IP setting.
LAN Current LAN IP setting.
Link Aggregation Current Link Aggregation status (N5200B only)
Disk Info Current status of disk slot has been installed
18
