Manual 0-4981 2-3 INTRODUCTION
2.05 Input Wiring Specifications
CutMaster A60 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I eff Fuse (amps)
Flexible Cord
(Min. AWG)
1 Phase
208 60 16 75 48 100 6
230 60 17 72 46 100 6
460 60 20 44 28 50 10
3 Phase
208 60 16 40 26 50 8
230 50/60 16 39 25 50 10
380 50/60 11.8 17 11 20 12
400 50/60 11.8 17 11 20 12
460 60 17 21 14 25 12
600 60 9.6 16 10 20 12
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
