Thermal Dynamics CUTMASTER 151 Service Manual

PARTS LISTS 6-8 Manual 0-4669
First & Second
Stage
Cartridges
(as marked)
Art # A-02942
Art # A-02476
Filter
Element
(Cat. No. 9-7741)
Housing
Cover
Barbed
Fitting
Spring
Assembled Filter
O-ring
(Cat. No. 9-7743)
6.08 Options and Accessories
Qty Description Catalog #
1 Single-Stage Filter Kit (Includes Filter And Hose) 7-7507
1 Replacement Filter Body 9-7740
1 Replacement Filter Element 9-7741
1 Replacement Filter Hose (Not Shown) 9-7742
1 Two Stage Air Line Filter Kit (Includes Hose & Mounting Screws) 7-7500
1 Bracket, Filter Mounting (Not Shown) 9-7535
1 Dual Stage Air Filter Assembly 9-7527
1 Replacement First Stage Cartridge 9-1021
1 Replacement Second Stage Cartridge 9-1022
Not Shown:
1 Extended Work Cable - 50 ft (15.2 m) 9-8350
1 Wheel Kit 9-8331
1 Nylon Dust Cover 9-7072
Single-Stage Filter Kit Two-Stage Filter Kit
