Thermal Dynamics Econo-Pak 50 User Manual

Manual 0-2450 9 INTRODUCTION & DESCRIPTION
SECTION 2: INTRODUCTION & DESCRIPTION
2.01 SYSTEM SPECIFICATIONS
Econo-pak 50
Air Plasma Cutting
System Includes:
Controls
Panel Indicators
Input Power
Output Power
OCV
Duty Cycle
Work Lead
Cut Capacity
Pilot Circuitry
Gas Connection
Gases
Pressure
Flow
Weight
Dimensions
• Econo-pak 50 - The power supply provides 35 amps maximum
output cutting current from a standard 208-230 volt, 60Hz AC
input service. All electrical, pilot, and gas control circuitry is
included.
• Hand Torch with Leads. Cut capacity is 1/2 inch (12.8 mm)
steel. Parts-In-Place (PIP) is an integral safety feature of this
torch to reduce the risk of electric shock.
• Spare Parts Kit.
• ON/OFF Switch
• RUN/SET Switch
• Output Current Control
• Pressure Regulator Control
LED Indicators: AC Power, READY
Pressure Gauge
208-230 VAC, 60 Hz, 25/30 Amp Single Phase
Continuously variable from 15 to 35 Amps maximum
330 VDC
40%
10 ft (3 m) with clamp
1/2 in (12.8 mm) Steel
Capacitor Discharge (CD), Pulsed DC
Rear panel entry 1/4 NPT
Compressed Air or Nitrogen (N
2
) Only
60 psi (4.2 BAR)
135 scfh (64 lpm)
70 lbs (32 kg) with 12.5' Torch Leads
20 3/4" (527 mm) High
9 3/4" (248 mm) Wide
25" (635 mm) Deep
