Manual 0-2450 11 INSTALLATION
What's Included with
the Power Supply
Unpacking Procedure
Choosing a Location
CAUTION
NOTE
Power Requirements
CAUTION
Included with each system is:
(1) Work Cable with Clamp (Attached)
(1) 230V Single-Phase, Three Wire Input Power Cable (Attached)
(1) Operating Manual
(1) Spare Parts Kit - Includes:
(5) Drag Cutting Tips..........................................Part No. 9-6501
(3) Electrodes .......................................................Part No. 9-6506
(1) Gas Distributor ..............................................Part No. 9-6507
1. Unpack each item and remove all packing material.
2. Inspect each item for possible shipping damage. If damage is
evident, contact your distributor and/or shipping company
before proceeding with system installation.
Select a clean, dry location with good ventilation and adequate
working space around all components.
The power supply is cooled by air flow through the front and
rear panels. Air flow must not be obstructed. Provide at least 12
inches (300 mm) clearance for both front and rear of system.
Operation without proper air flow will inhibit proper cooling and
reduce duty cycle.
Review Important Safety Precautions (page iii) to be sure that the
selected location meets all safety requirements.
The unit will operate on single phase 208-230 VAC, 60 Hz. The
service should be fused for 30 amps.
The primary power source, power cable, and plug must conform
to local electric code and recommended circuit protection and
wiring requirements.
SECTION 3: INSTALLATION
3.01 UNPACKING AND CHOOSING A LOCATION
3.02 ELECTRICAL CONNECTIONS
