Remote Control Panel Features (Rev. 04/03)
30
2. Press the Select key repeatedly to show the prompt and display screens.
The prompt and display screens will appear in the order shown below:
[ALr] Alarm codes if present. If no codes exist this screen will not appear.
[CYCLS] CYCLE SENTRY or Continuous mode prompt screen. [YES] - CYCLE SENTRY; [no] = Continuous
[
dIS] Discharge air temperature as measured by the discharge temperature sensor.
[coL] Evaporator coil temperate as measured by the evaporator coil temperature sensor.
[tLH] Total amount of time in hours the unit has been turned ON with the keypad On key.
[EnH] Total amount of time in hours the diesel engine has run.
[ELH] Total amount of time in hours the electric motor has run (on units equipped with Standby).
[Hr4] Total accumulated hours on hourmeter 4 (only appears if this hourmeter is set to Type 1, 2 or 3).
[Hr5] Total accumulated hours on hourmeter 5 (only appears if this hourmeter is set to Type 1, 2 or 3).
[Hr6] Total accumulated hours on hourmeter 6 (only appears if this hourmeter is set to Type 1, 2 or 3).
[oIL
] Diesel engine oil pressure.
[Ent] Diesel engine coolant temperature.
[rPn] Diesel engine RPM.
[bAt] Battery voltage of the unit battery.
[bLIt] Backlight select (allows the driver to select high or low backlight illumination level).
[dFI] Initial defrost interval.
[ddr] Defrost duration.
Each prompt or display screen will remain on the display for about 10 seconds. If no other key is pressed, the display will then
return to the Standard Display of box temperature and setpoint.
Locking a Display Screen on the Display
The display screens in the list above that are underlined
can be locked on the display. Select the desired display screen by
pressing the Select key and then press the Enter key. The display will now remain on the screen until any other key is pressed.
