ProReact EN Analogue Installation Manual
Document Ref. PACC-MAN
VdS EN54-22:2015+A1:2020 Approval
Approval Specics
Certicate No: G 220006
Holder of the Approval: Thermocable Flexible Elements Ltd, Pasture Lane, Clayton, Bradford, BD14 6LU UK
Subject of Approval: Resettable line-type heat detector (ProReact EN Analogue)
Use: in automatic re detection and re alarm systems
Basis of Approval: VdS 2344:2014-07
VdS 2543:2018-05
EN54-22:2015+A1:2020
Environmental Group: II (All components)
Approval Components
Part No Description EN54-22 Denition
A1389 ProReact EN Analogue Composite Control (PACC) Unit Sensor Control Unit
A1470 ProReact EN Analogue End-of-line Unit Functional Unit
A1471 ProReact EN Analogue Junction Box Functional Unit
F3050 ProReact EN Analogue PVC Coated Sensor Cable Sensing Element
F3051 ProReact EN Analogue Nylon Coated Sensor Cable Sensing Element
F3052 ProReact EN Analogue PVC and Stainless Steel braided Sensor Cable Sensing Element
Response Classes
Sensor
Control Unit
Sensing
Element
Controller
Parameter
Response
Classication
Max Sensor
Cable Zone
Length
Min Sensor
Cable Zone
Length
Typical
Application
Temperature
Max
Application
Temperature
ProReact EN
Analogue
Composite
Control Unit
ProReact EN Analogue PVC
Coated Sensor Cable
Class A1I/A2I A1I 500m 50m 25°C 50°C
ProReact EN Analogue
Nylon Coated Sensor Cable
ProReact EN Analogue PVC
and Stainless Steel braided
Sensor Cable
ProReact EN
Analogue
Composite
Control Unit
ProReact EN Analogue PVC
Coated Sensor Cable
Class A1I/A2I A2I 500m 50m 25°C 50°C
ProReact EN Analogue
Nylon Coated Sensor Cable
ProReact EN Analogue PVC
and Stainless Steel braided
Sensor Cable
ProReact EN
Analogue
Composite
Control Unit
ProReact EN Analogue PVC
Coated Sensor Cable
Class BI BI 500m 30m 40°C 65°C
ProReact EN Analogue
Nylon Coated Sensor Cable
ProReact EN Analogue PVC
and Stainless Steel Braided
Sensor Cable
