ThinkPad E555 - Right-Side View

Right-sideview
Figure3.Right-sideview
1Comboaudioconnector2Opticaldrive(availableonsomemodels)
3USB2.0connector
4acpowerconnector
5LenovoOneLinkconnector
1Comboaudioconnector
Connectaheadphonesoraheadsetthathasa3.5-mm(0.14-inch)4-poleplugtotheaudioconnectorto
listentothesoundfromthecomputer.
Notes:
•Ifyouareusingaheadsetwithafunctionswitch,donotpressthisswitchwhileusingtheheadset.If
youpressit,theheadsetmicrophonewillbedisabled,andtheintegratedmicrophonesonthecomputer
willbeenabledinstead.
•Thecomboaudioconnectordoesnotsupportaconventionalmicrophone.Formoreinformation,see
“Usingaudiofeatures”onpage40.
2Opticaldrive(availableonsomemodels)
Usetheopticaldrivetoreadorburnopticaldiscs.
3USB2.0connector
TheUniversalSerialBus(USB)2.0connectorisusedforconnectingUSB-compatibledevices,suchasa
USBprinteroradigitalcamera.
Note:WhenyouattachaUSBcabletothisUSBconnector,ensurethattheUSBmarkisfacingupward.
Otherwisetheconnectormightgetdamaged.
Chapter1.Productoverview5
