•“1030Largebottomcover”onpage66
•“1040Smallbottomcover”onpage67
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdriveorsolid-statedrive”onpage70
•“1080WirelessWANcardorM.2solid-statedrive”onpage72
•“1090WirelessLANcard”onpage75
•“1100Coin-cellbattery”onpage76
•“1110Fanassembly”onpage76
•“1120Keyboard”onpage79
•“1130Keyboardbezelassembly”onpage85
•“1150Systemboard”onpage88
•“1160Media-card-reader/USBcard”onpage92
Removalstepsofthespeakerassembly
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated,bighead(4)
Black0.181Nm
(1.85kgf-cm)
98HardwareMaintenanceManual
