ThinkPad Edge E540 - 2020 LCD Panel;Screen Assembly and LCD Rear Cover

2020LCDpanel/screenassemblyandLCDrearcover
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage65
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
•“1040Smallbottomcover”onpage67
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdriveorsolid-statedrive”onpage70
•“1080WirelessWANcardorM.2solid-statedrive”onpage72
•“1090WirelessLANcard”onpage75
•“1100Coin-cellbattery”onpage76
•“1120Keyboard”onpage79
•“1130Keyboardbezelassembly”onpage85
•“1150Systemboard”onpage88
•“1180DC-inbracket”onpage95
•“1190DC-in/Ethernetcard”onpage96
•“1220LCDunit”onpage100
•“2010LCD-hingecaps”onpage114
RemovalstepsoftheLCDpanel/screenassemblyandLCDrearcover
1
1
1
1
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2.5×5mm,wafer-head,nylon-coated(8)Silver
0.181Nm
(1.85kgf-cm)
116HardwareMaintenanceManual
