Wheninstalling:Plugthegraycableintothemainconnector,andtheblackcableintotheauxiliary
connectoronthecard.
1100Coin-cellbattery
Foraccess,removetheseFRUsinorder:
“1020Batterypack”onpage65
“1040Smallbottomcover”onpage67
Removalstepsofthecoin-cellbattery
DANGER
Useonlytheauthorizedbatteryspeciedforyourcomputer.Anyotherbatterycouldigniteor
explode.
2
1
Wheninstalling:Ensurethattheconnectorisattachedrmly.
1110Fanassembly
Foraccess,removetheseFRUsinorder:
“1020Batterypack”onpage65
“1030Largebottomcover”onpage66
76HardwareMaintenanceManual
