Removalstepsofthefanassembly
1.Detachtheconnector.
1
Wheninstalling:Ensurethattheconnectorisattachedrmlytothesystemboard.
2.Loosenthescrewsinascendingalphabeticalorderasillustrated.
Note:Differentmodelsmighthavedifferentnumbersofscrews.
2g
2f
3a
2c
2b
2d
2a
3b
2e
Chapter9.RemovingorreplacingaFRU77
