ThinkPad Edge E540 - 1130 Keyboard Bezel Assembly

7.Turnthecomputeroverandlockthekeyboardframe.
11
1130Keyboardbezelassembly
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdriveorsolid-statedrive”onpage70
•“1120Keyboard”onpage79
Removalstepsofthekeyboardbezelassembly
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
StepScrew(quantity)Color
Torque
1
M2×8mm,wafer-head,nylon-coated(12)
Black0.181Nm
(1.85kgf-cm)
2
M2×5mm,wafer-head,nylon-coated(3)
Black0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU85
