ThinkPad Edge E540 - 1070 Hard Disk Drive or Solid-State Drive

Wheninstalling:
Note:Ifonlyonememorymoduleistobeinstalledonthecomputeryouareservicing,thememorymodule
mustbeinstalledininthelowermemoryslota(SLOT-0),nottheuppermemoryslotb(SLOT-1).
b
a
Insertthenotchedendofthememorymoduleintotheslotatanangleofabout20degrees.Pressthe
memorymodulermly,andpivotitdownwardsuntilitsnapsintoplace.Ensurethatthememorymoduleis
rmlyinstalledintheslotanddoesnotmoveeasily.
1070Harddiskdriveorsolid-statedrive
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
Attention:
•Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.Improper
handlingcancausedamageandpermanentlossofdata.
•Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
•Neverremovethedrivewhilethecomputerisoperatingorisinsuspendmode.
70HardwareMaintenanceManual
