ThinkPad Edge E540 - 1090 Wireless LAN Card

1090WirelessLANcard
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage65
•“1040Smallbottomcover”onpage67
RemovalstepsofthewirelessLANcard
Instep1,unplugtheconnectorsbyusingtheantennaRFconnectorremovaltoolorpicktheconnectors
withyourngersandgentlyunplugthemasshown.
2
1
1
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
Chapter9.RemovingorreplacingaFRU75
