ThinkPad Edge E540 - 2030 LCD Hinges

RemovalstepsoftheLCDpanel
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×2.5mm,wafer-head,nylon-coated,smallhead(4)
Black0.181Nm
(1.85kgf-cm)
3
4
2
Wheninstalling:EnsurethattheLCDconnectorisattachedrmly.
2030LCDhinges
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage65
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
