ThinkPad Edge E540 - 1170 Optical-Drive Card

2
1
3
Wheninstalling:Ensurethattheconnectorisattachedrmlytothesystemboard.
StepScrew(quantity)Color
Torque
3
M2×5mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
4
1170Optical-drivecard
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage65
•“1030Largebottomcover”onpage66
Chapter9.RemovingorreplacingaFRU93
