ThinkPad Edge E540 - 1030 Large Bottom Cover

Unlockthebatterypacklatch1.Holdthebatterypacklockleverintheunlockedposition2andremovethe
batterypack3.
3
2
1
Wheninstalling:Installthebatterypackintotheslot.Ensurethatthebatterypacklatchisinthelocked
position.
1030Largebottomcover
Foraccess,removethisFRU:
•“1020Batterypack”onpage65
Removalstepsofthelargebottomcover
Loosenthescrews1andthenremovethelargebottomcover2.
1
1
1
2
66HardwareMaintenanceManual
