Chapter7.Locations
Thischapterintroducesthelocationsofthehardwarecomponentsonyourcomputer.
Locatingcomputercontrols,connectors,andindicators
Thistopicintroducesthelocationsofthecomputercontrols,connectors,andindicators.
Frontview
5
4
6
7
1
1
2
8
9
10
12
11
3
1Microphones
7Always-OnUSBconnector
2Camera(onsomemodels)8System-statusindicator
1
3LenovoOneLinkconnector9Fingerprintreader(onsomemodels)
4acpowerconnector
10ThinkPadtrackpad
5Ethernetconnector11TrackPoint
®
pointingstick
6Opticaldriveoroptical-drivebaybezel
12Powerbutton
1
:Forthedescriptionofthesystem-statusindicator,seeChapter5“Statusindicators”onpage45.
