ThinkPad Edge E540 - Rear View; Bottom View; Locating Frus and Crus

Rearview
1
2
3
4
5
6
1System-statusindicator
1
4High-DenitionMultimediaInterface(HDMI™)
connector
2Comboaudioconnector5VGAconnector
3USB3.0connectors6Security-lockslot
1
:Forthedescriptionofthesystem-statusindicator,seeChapter5“Statusindicators”onpage45.
Bottomview
3
2
2
1
4
5
6
1Smallbottomcover
1
4Largebottomcover
2
2Batterypacklatches
5Speakers
3Batterypack6Mediacardslot
1
:ThewirelessLANcardandcoin-cellbatteryarelocatedunderneaththesmallbottomcover.
2
:Thememorymodules,harddiskdriveorsolid-statedrive,andwirelessWANcardorM.2solid-state
drivearelocatedunderneaththelargebottomcover.
LocatingFRUsandCRUs
Thistopicintroducesthefollowingserviceparts:
•“MajorFRUsandCRUs”onpage52
50HardwareMaintenanceManual
