•“1040Smallbottomcover”onpage67
•“1050Opticaldriveoroptical-drivebaybezel”onpage68
•“1070Harddiskdriveorsolid-statedrive”onpage70
•“1080WirelessWANcardorM.2solid-statedrive”onpage72
•“1090WirelessLANcard”onpage75
•“1100Coin-cellbattery”onpage76
•“1120Keyboard”onpage79
•“1130Keyboardbezelassembly”onpage85
•“1150Systemboard”onpage88
•“1180DC-inbracket”onpage95
•“1190DC-in/Ethernetcard”onpage96
•“1220LCDunit”onpage100
•“2010LCDbezel”onpage106
RemovalstepsoftheLCDhinges
2
2
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2×3.5mm,wafer-head,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(2)
Black0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU109
