ReleasetheantennacablesfromthecableguidesontheLCDrearcover.
1 1 1 1
2
2
2
2
11
3
3
Cablerouting:Whenyouinstallthewirelessantennaassembly,routethecablesasshowninthefollowing
illustration.
Attention:Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
