ThinkPad T420 - 1160 LCD Unit

1160LCDunit
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage67
•“1020ExpressCardblankbezel”onpage68
•“1050DIMMslotcover”onpage73
•“1070PCIExpressMiniCardforwirelessWAN”onpage75
•“1080Keyboard”onpage77
•“1110PCIExpressMiniCardforwirelessLAN”onpage85
•“1120Keyboardbezelassembly,FPCcable,andBluethoothdaughtercard”onpage87
RemovalstepsofLCDunit
1
1
StepScrew(quantity)Color
Torque
1
M2.5×6mm,wafer-head,nylon-coated(2)
Black0.392Nm
(4.0kgf-cm)
