ThinkPad T420 - 1110 PCI Express Mini Card for Wireless LAN

1110PCIExpressMiniCardforwirelessLAN
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage67
•“1050DIMMslotcover”onpage73
•“1080Keyboard”onpage77
RemovalstepsofPCIExpressMiniCardforwirelessLAN
Instep1,unplugthejacksbyusingtheremovaltoolantennaRFconnector(P/N:08K7159),orpickthe
connectorswithyourngersandgentlyunplugtheminthedirectionofthearrow.
Note:Somemodelsmighthaveonlytwoantennacables.
StepScrew(quantity)Color
Torque
2
M2×10mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
Chapter8.RemovingandreplacingaFRU85
