ThinkPad T420 - 1210 System Board and Expresscard Slot Assembly

1210SystemboardandExpressCardslotassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage67
•“1020ExpressCardblankbezel”onpage68
•“1030SerialUltrabayEnhanceddeviceortravelbezel”onpage69
•“1040Harddiskdrive(HDD)andsolidstatedrive(SSD)”onpage70
•“1050DIMMslotcover”onpage73
•“1070PCIExpressMiniCardforwirelessWAN”onpage75
•“1080Keyboard”onpage77
•“1110PCIExpressMiniCardforwirelessLAN”onpage85
•“1120Keyboardbezelassembly,FPCcable,andBluethoothdaughtercard”onpage87
•“1150Speakerassembly”onpage95
•“1160LCDunit”onpage97
•“1170Fanassembly”onpage101
•“1180CPU”onpage105
•“1190BasecoverassemblyandDC-inconnectorcable”onpage106
Importantnoticesforhandlingthesystemboard:
Whenhandlingthesystemboard,bearthefollowinginmind.
•Thesystemboardhasanaccelerometer,whichcanbebrokenbyapplyingseveralthousandsofG-forces.
Note:Droppingasystemboardfromaheightofaslittleas6inchessothatitfallsatonahardbenchcansubject
theaccelerometertoasmuchas6,000G'sofshock.
•Becarefulnottodropthesystemboardonabenchtopthathasahardsurface,suchasmetal,wood,orcomposite.
•Ifasystemboardisdropped,testitusingPC-DoctorforDOSifthesystemsupportsPC-DoctorforDOS,tomake
surethattheHDDActiveProtectionSystem™stillfunctions.
Note:IfthetestshowsthatHDDActiveProtectionSystemisnotfunctioning,besuretodocumentthedropina
rejectreport,andreplacethesystemboard.
•Avoidroughhandlingofanykind.
•Ateverypointintheprocess,besurenottodroporstackthesystemboard.
•Ifyouputasystemboarddown,besuretoputitonlyonapaddedsurfacesuchasanESDmatoracorrugated
conductivesurface.
IfthesystemsupportsPC-DoctorforDOS,afterreplacingthesystemboard,runPC-DoctorforDOStomakesurethat
HDDActiveProtectionSystemstillfunctions.Theprocedureisasfollows:
1.Placethecomputeronahorizontalsurface.
2.RunDiagnostics➙ThinkPadDevices➙HDDActiveProtectionT est.
Attention:Donotapplyphysicalshocktothecomputerwhilethetestisrunning.
RemovalstepsofsystemboardandExpressCardslotassembly
Thefollowingcomponentssolderedonthetopsideofthesystemboardareextremelysensitive.Whenyou
servicethesystemboard,avoidanykindofroughhandling.
a
CPU
b
AccelerometerchipfortheHDDActiveProtectionSystem
112ThinkPadT420andT420iHardwareMaintenanceManual
