ThinkPad T420 - 1040 Hard Disk Drive (HDD) and Solid State Drive (SSD)

1040Harddiskdrive(HDD)andsolidstatedrive(SSD)
Foraccess,removethisFRU:
•“1010Batterypack”onpage67
Attention:
•Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.Improper
handlingcancausedamageandpermanentlossofdata.
•Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
•Neverremovethedrivewhilethesystemisoperatingorisinsuspendmode.
Removalstepsofharddiskdriveandsolidstatedrive
Note:Loosenthescrew1,butdonotremoveit.
4
4
2
1
StepScrew(quantity)Color
Torque
1
Capturescrew(1)
Black0.181Nm
(1.85kgf-cm)
70ThinkPadT420andT420iHardwareMaintenanceManual
