ThinkPad T420 - Chapter 9. Locations; Front View

Chapter9.Locations
ThischapterpresentsthelocationsofThinkPadT420andT420ihardwarecomponents.
Frontview
1
Integratedcamera(forsomemodels)
2
ThinkLight
3
Built-inmicrophone
4
Built-inspeakers
5
Securitykeyhole
6
Universalserialbus(USB)/eSATAcomboconnector
7
USBconnector
8
MediaCardReaderslot
9
ExpressCardslot
10
SerialUltrabayEnhanceddriveortravelbezel
11
Comboaudiojack
12
Fingerprintreader
13
Touchpadbuttons
14
Touchpad
15
TrackPointbuttons
16
TrackPointpointingstick
17
UltraNav
18
Volumecontrolbuttons
19
ThinkVantagebutton
20
Powerswitch
21
Statusindicators
Note:Forthedescriptionofeachindicator,seeChapter5“Statusindicators”onpage53.
©CopyrightLenovo2012
129
