ThinkPad T420 - Rear View

Rearview
1
Statusindicators
Note:Forthedescriptionofeachindicator,seeChapter5“Statusindicators”onpage53
.
2
SmartCardslot
3
DisplayPortconnector
4
USBconnector
5
RJ-45(Ethernet)connector
6
Externalmonitorconnector
7
Powerjack
8
USBconnector
9
ModemconnectororIEEE1394
5
6
3
2
4
5
7
8
9
1
6
Chapter9.Locations131
