1030SerialUltrabayEnhanceddeviceortravelbezel
Foraccess,removethisFRU:
•“1010Batterypack”onpage67
RemovalstepsofSerialUltrabayEnhanceddeviceortravelbezel
Holdingthebaylocklatchintheunlockedposition1,slidethebayejectlatchinthedirectionshownby
arrow2,andthenpullouttheSerialUltrabayEnhanceddeviceorthetravelbezelinthedirectionshownby
arrow3tocompletelyremoveit.
3
2
1
Chapter8.RemovingandreplacingaFRU69
