ThinkPad T420 - 1120 Keyboard Bezel Assembly, FPC Cable, and Bluethooth Daughter Card

1120Keyboardbezelassembly,FPCcable,andBluethoothdaughter
card
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage67
•“1020ExpressCardblankbezel”onpage68
•“1050DIMMslotcover”onpage73
•“1080Keyboard”onpage77
Note:TheFPCcableisattachedontheundersideofthekeyboardbezelassembly.Insomemodels,the
Bluetoothdaughtercardisalsoattachedontheundersideofthekeyboardbezelassembly.Forthemodels
thatdonothaveaBluetoothdaughtercard,skipsteps8to10.
Removalstepsofkeyboardbezelassembly,FPCcable,andBluetoothdaughtercard
2
2
2
2
1
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
2
M2×15mm,wafer-head,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
Chapter8.RemovingandreplacingaFRU87
