ThinkPad T420 - 2060 Wireless LAN Antenna Assembly or Wireless LAN;WAN Antenna Assembly

2060WirelessLANantennaassemblyorwirelessLAN/WANantenna
assembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage67
•“1020ExpressCardblankbezel”onpage68
•“1050DIMMslotcover”onpage73
•“1070PCIExpressMiniCardforwirelessWAN”onpage75
•“1080Keyboard”onpage77
•“1110PCIExpressMiniCardforwirelessLAN”onpage85
•“1120Keyboardbezelassembly,FPCcable,andBluethoothdaughtercard”onpage87
•“1150Speakerassembly”onpage95
•“1160LCDunit”onpage97
•“2010LCDbezelassembly”onpage116
•“2020LEDboard”onpage117
•“2030Integratedcamera”onpage119
•“2040LCDpanelandLCDcable”onpage121
•“2050Cameracable”onpage123
RemovalstepsofwirelessLANantennaassemblyorwirelessLAN/WANantennaassembly
1
1
1
1
1
1
2 2 2 2
1
1
Wheninstalling:Whenyouinstalltheantennakit,routethecablesasshowninthegureabove.Asyou
routethecables,makesurethattheyarenotsubjectedtoanytension.Tensioncouldcausethecablestobe
damagedbythecableguides,orawiretobebroken.
124ThinkPadT420andT420iHardwareMaintenanceManual
