ThinkPad T420 - Page 105

StepScrew(quantity)Color
Torque
6
M2.5×6mm,wafer-head,nylon-coated(2)
Black0.392Nm
(4.0kgf-cm)
7
7
8
7
Wheninstalling:
•Makesurethatyouattachtheconnectorsrmly.
•Makesurethatyouroutethecablescorrectlyandyoutapeupintheproperpositionsasshownin
theabovegure.
•Whenyouroutethecables,makesurethattheyarenotsubjectedtoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
Chapter8.RemovingandreplacingaFRU99
