Table12.Partslist—Miscellaneousparts(continued)
FRUFRUno.
CRU
ID
•Insulationsheet-ngerprint
•LCDlatchleft
•LCDlatchright
•LCDlink
•LCDlatchspring
Systemmiscellaneousparts:
•(a)Expressdummycard
•(b)LCDconnectorbracket
•(c)Fanbracket,discrete
•CPUmylarfor35WSVGT2
•1394cover
•Dummycover,RJ-11
•Plasticsupportforsmartcard
•BlindsheetforSIMcard
•SIMdummycard
Note:Italicizedlettersinparenthesesarereferencestotheexplodedviewin“Overall”
onpage134
.
04W1604N
Systemboardmiscellaneousparts:
•Insulationsheet-MB
•Insulationsheet-DDR
•Insulationsheet-expresscard
•Insulationsheet-battery
•Insulationsheet-docking
•Insulationsheet-bottomhole
•Insulationsheet-DC-in
•Bracket-expresscard
•SIMguidebracketsubaccessory
•CPUbracketsubaccessory
•SIMslidespacer
•SIMpulltab
•SpongeforRJ45connector
•Spongefordisplayportconnector
•SpongeforHDD1
•SpongeforHDD2
•SpongeforHDD3
•SpongeforODD1
•SpongeforODD2
04W1601N
LCDmiscellaneousparts:
•LCDfrontbezel
•Rubber-LCDfrontbezel
•Stopper-LCDfrontbezel
•LEDlens-LCDfrontbezel
•Shield-EMC
•Clearplate-LCDrearcover
•LEDlens-LCDrearcover
•ThinkPadlogo
•Lenovologo
•LCDlatch-right
•LCDlatch-left
•Sponge-center
•Sponge-upper
•Sponge-lower
•Stopper-upperright
•Stopper-upperleft
•Stopper-lowerright
•Stopper-lowerleft
04W1607N
