6 Connection options
To the left beneath the keyboard you nd the headphones outlets 1 and 2.
Connecting headphones (not supplied) to the outputs mutes the speakers.
Use the [LINE OUT] socket to connect the digital piano to an amplier, stereo device,
mixing console or recording device. Plug one end of the audio cable into the
[LINE OUT] socket on the rear panel of the digital piano and the other end into the
input of the respective audio device.
NOTICE!
To prevent damage to the speakers, turn the volume down to ‘Mini‐
mum’ before you connect other devices to the digital piano.
Use the [AUX IN] socket to connect a, for example, CD or MP3 player to the digital
piano. So you can playback music through the internal speakers of the digital piano
and simultaneously play along to it. Plug one end of the audio cable into the [AUX IN]
socket on the rear panel of the digital piano and the other end into the output of the
respective audio device.
You can connect the digital piano to a PC for data exchange via the USB-to-host
interface. You can also connect the digital piano to smartphones, tablets or other
mobile devices and control it using a suitable app (e.g. PianoToolBox).
Use the MIDI interface to send MIDI data to an external MIDI device.
Headphones
External audio devices via LINE OUT
External audio devices via AUX IN
Computer via USB-MIDI
MIDI device via MIDI OUT
Connection options
DP-28 Plus
13
