TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 1 09/02/27 Thomson Technology
9
LD ON GEN (PROG 4) LED illuminates whenever the Programmable output Relay
#4 is turned on (relay on the circuit board is energized).
Factory default function is “Load on Gen”.
LD ON UTIL (PROG 5) LED illuminates whenever the Programmable output Relay
#5 is turned on (relay on the circuit board is energized).
Factory default function is “Load on Utility”.
2.3. TSC 80e CONTROLLER FEATURES
The Thomson Technology TSC 80e Transfer Switch Controller utilizes the latest
advancements in microprocessor technology, printed circuit board assembly and software for
control of automatic transfer switches. The TSC 80e is the second generation of
microprocessor-based transfer switch controllers from Thomson Technology, and reflects over
30 years of transfer switch control experience. The TSC 80e is factory configured to monitor,
display and control all operational functions of the automatic transfer switch. All voltage
sensors and timers are fully user adjustable utilizing software configuration. The
microprocessor design provides high accuracy for all voltage sensing and timing functions as
well as providing many standard features.
• Utility AC voltage sensing (true RMS) – 120-600V single phase or 3 phase
• Generator AC voltage sensing (true RMS) – 120-600V single phase or 3 phase
• Generator AC frequency sensing
• Utility under voltage control setpoint 70 - 95% (adjustable)
• Generator under voltage control setpoint 70 - 95% (adjustable)
• Generator under frequency control setpoint 70 - 90% (adjustable)
• Engine warm-up timer 0-60 sec. (adjustable)
• Utility return timer 0-30 min. (adjustable)
• Engine start timer 0-60 sec. (adjustable)
• Engine cooldown timer 0-30 min. (adjustable)
• Neutral position delay timer 0-60 sec. (adjustable)
• Local utility power fail simulation test pushbutton & LED, door mounted
• Remote utility power fail simulation test pushbutton input (via terminal block)
• Load on utility supply & load on generator supply LED’s, door mounted
• Utility and generator source available LED’s, door mounted
• Weekly plant exercise timer (30 min. on load) manually initiated
