TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 1 09/02/27 Thomson Technology
27
4. TSC 80e SOFTWARE PROGRAMMING INSTRUCTIONS
4.1. PASSWORDS
Access to the programmable parameters of the TSC 80e Transfer Controller is via a security
password number. Two levels of security passwords are provided as described below:
4.1.1. USER READ (VIEW ONLY MODE)
User can view any programming parameter as required. No Password is required for
the VIEW ONLY MODE. To enter the VIEW ONLY MODE to review programming
settings, follow the procedure as listed below:
1. Press the ENTER key.
2. Press the DOWN or UP keys to scroll through the available programming
menus.
3. Once the selected program menu is displayed, press the ENTER key to view
the sub-menus available.
4. Press the DOWN or UP keys to scroll through the programming sub-menus
available.
5. Once the selected program sub-menu item is displayed, press the ENTER key
to view the selected value.
To exit the programming sub-menus, press the ESC key. To exit back to the normal
display mode, press the ESC key again.
4.1.2. USER READ / WRITE MODE
User password can view and modify all programming parameters except sub-
menu items “Clear System Statistics”, “Clear Data Log”, “Set Voltage
Calibrations” & “System Options”. User password can also modify the User
password number. The Factory default number for the User read/write mode is
one (01).
4.1.3. MASTER READ / WRITE MODE
Master password can view and modify all programming parameters except items in the
“System Options” sub-menu. Master password can also modify the User password
number. Consult THOMSON TECHNOLOGY factory for master password number if
required.
