TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 1 09/02/27 Thomson Technology
37
3. For nominal system voltages that are not provided by specific
software values, refer to Section 4.6.5.2
When a system voltage is selected, the TSC 80e’s utility and generator under
voltage setpoint percentage setting will be automatically programmed to
correspond to the sensing input voltage (e.g. with a 600V system voltage
selected, and a 80% under voltage software setting, the under voltage sensor
will be activated below 540VAC).
