14 HA0338T Rev C July 2022

Chapter 3

Fig. 3.4 Top Plate Detail

(1.22”)

30.9 mm

(0.86”)

21.8 mm

(1.18”)

30.0 mm

4-40 UNC

3.5 mm (0.137”) MAX

THIS AND OPPOSITE SIDE

FOR CAGE SYSTEM

SM1 THREAD

(4 PLACES)

FOR USE WITH K6A1

PLATFORM MOUNT

M3 (4-40 UNC) 6.0 mm (0.24”) M3 (4-40 UNC) 6.0 mm (0.24”)

(2 PLACES)

FOR USE WITH ADAPTOR

K10CR1A2
