THORLABS K10CR1 User Manual

13
K10CR1 Cage Rotation Stage
3.5 Dimensions
3.5.1 K10CR1 Dimensions
Fig. 3.3 Stage Dimensions
12.5 (0.5”)
11.0 (0.43”)
M4 (8-32 UNC) 5.0 (0.2”) 2 PLACES
FOR POST MOUNTING
M4 (8-32 UNC)
6.0 (0.24”)
FOR POST
MOUNTING
16.0 (0.63”) 29.0 (1.14”)
66.0 (2.6”)Ø 6.0 (0.24”) 2 PLACES
(Note A)
107.0 (4.21”)
R 26.0
(1.02”)
35.5 (1.4”)
21.5
(0.85”)
25.0
(1.0”)
4.5
(0.18”)
21.0
(0.83”)
21.5
(0.84”)
23.5
(0.93”)
21.0
(0.83”)
35.0
(1.38”)
2.0
(0.08”)
15.2
(0.59”)
M4 (8-32 UNC)
8.0 (0.31”) 3 PLACES
FOR USE WITH
ADAPTER K10CR1A1 (/M)
Notes.
A. Use with cage rods to aid
alignment when close
mounting several stages
All dimensions in millimeters (inches)
